Skarke Ventilsysteme (valve systems), an internationally oriented company, has stood for innovative reliable products and first-class service for nearly 20 years. Well-known companies in Europe, Asia and overseas rely on Skarke Ventilsysteme initial equipment as well as for re-fitting. Our customers come from a variety of industries, such as construction, agriculture, the automotive industry, and motor and gearbox manufacture as well as plant construction.

Our valves are used in fluidics, in oil, cooling water and fuel management.

Quality and an ability to deliver are an important part of our success.

We carry out sales, production and quality monitoring exclusively in our own plant. Our motivated and long-serving employees are as much part of our success as our chosen reliable contractors.

Production

Our customers demand not only products of the highest quality but also availability and timely delivery.

We control every step, from development and manufacturing of samples through to production of the finished product. This way we are able to deliver quality products quickly, efficiently and in a customer-oriented way.

We ensure optimum quality for everything from unique specimens to mass production by using modern production and assembly facilities.

Computer-supported purchasing and production planning guarantee the availability of components as well as flexible production and delivery times.

Quality management

Customer orientation is our means for economic success. This model influences our actions.

Since 1999, the DQS (international competence centre for the assessment and certification of management systems ) has been facilitating our aim to continue developing and implementing the high quality we set ourselves as standard.

We now follow the regulations set down in DIN EN ISO 9001:2000, certificate number 083061 QM

We are always prepared to revise and improve our management structures systematically, and this is an important base for customer satisfaction as well as company development.

Products for innovative solutions. Our extensive high quality product range, made of media compatible materials, offer the user a broad choice of applications. Constant redevelopment of our tried and tested product series means that we always use modern and cost-effective new technologies.

Oil service valves

Skarke oil service valves are the ideal solution for individual demands wherever oils and water emulsions are used.

Our complete system is designed so that the majority of problems can be solved using combinations of the different series.

Tried and tested partial solutions can be combined with newly developed components to provide economically viable solution for specific problems.

Skarke oil service valves are used to make maintenance of closed systems for oil and media containing oil safe, easy and environmentally friendly anywhere.

Series 45

This valve series is suitable for 98% of tasks. Depending on the dimensions, the valve bodies are made of either brass or chromated steel. We can deliver all standard screw in threads from stock at short notice. For an overall length of approx. 41 mm the length of the screw in threads is 10 mm or 18 mm. Protective caps can be delivered with or without a chain or steel cable. The dimensions of the connecting thread are M 22 x 1,5 or M 26 x 1,5.

We can also provide product versions in different materials and with different screw thread dimensions.

Series 45L

This series is the same as series 45 in type, apart from the overall length of approx. 61 mm.

We can not deliver all sizes of screw threads immediately from stock.

Series 25 SA

This valve series makes it possible to move the removal position to a different place using a hydraulic hose connected to the oil service valve. We can deliver a variety of screwed ends as series. Other types are available on request.

The valve body is made of chromate steel.

Series 23

In this series we can deliver installation lengths between approx. 75 mm and approx. 175 mm. The valves are used for devices that have unfavorable space conditions, such as casings or frame parts. The valve body is made of chromate steel. The protective caps, valve heads and insides are made of brass.

Series 75

Series 75 is, at present, the largest valve in our range, with screw in thread G 1 ?" and an aperture of approx. 1". The version and material can be adapted to requirements.

Series 10 This is our smallest valve, with screw in thread M10 and valve body SW 19. It is mainly used for ventilation or sampling points.

Series 40 - Connections

Series 40, "connections", provides a large variety of connection combinations. Straight, 90? or 45? connections can be used to combine hose lengths of 250 mm, 500 mm and 1000 mm in series. We can deliver different lengths on request.

Spare parts and accessories

Our accessories offer users a large variety of further solutions to specific problems.
